Detroit Diesel DiagnosticLink Standard

Detroit DiagnosticLink Standard

The standard edition provides ECU information, diagnostic fault codes, instrumentation and run system tests, and edit ECU parameters.

ECUs are supported for the following products:

  • EPA07 – DD15, DD13, DD16, S60, MBE900, MBE4000
  • EPA10 – DD13, DD15, DD16
  • GHG14 – DD13, DD15, DD16, DT12 Transmission
  • Freightliner Cascadia
  • Western Star 5700XE

DDDL 6.50 is included with this version to support Legacy engines.

NOTE: Windows 10 or higher is required.

Engines Supported in Detroit DiagnosticLink Standard:
  • EPA07 – DD15, DD13, DD16, Series 60, MBE900, MBE4000
  • EPA10 – DD15, DD13, DD16
  • GHG14 – DD13, DD15, DD16, DT12 Transmission
  • Freightliner Cascadia
  • Western Star 5700XE

*ECU access is based on Organization type

Note: Computer must be connected to the internet during activation
Note: Requires annual renewal
Diagnostic Coverage
  • Fault Codes
  • Cylinder Cutout
  • Diagnostic Instrumentation
  • Normal Instrumentation
  • Engine Configuration Data
  • ECM I/O
  • Injector Response Time
  • Maintenance Alert
  • View Observed MIDs
  • Exhaust Back Pressure Fault Times
  • View information about connected ECUs
  • Read variable values in real time and display them graphically
  • Configure and manage parameters
  • Play back logs of all connected activity
Additional Detroit DiagnosticLink Standard Features:
  • Engine & Trip Data
  • DDEC Reports
  • Clear AFR Learn Table
  • Particulate Filter Reset
  • Recalibrate NG Oxygen Sensor
  • Recalibrate EGR Delta Pressure Sensor
  • Calibration Passwords
  • Injector Calibration
  • Engine Configuration Data
Detroit Diesel DiagnosticLink System Requirements:
  • IT Security Firewall Access for TCP Port 48481 and server name ‘dtna-DlrInfo.prd.freightliner.com’
  • Windows 10 Professional
  • 2.0 GHz Dual-Core processor or greater
  • 2 GB RAM or more
  • 40 GB hard drive with 20 GB free space
  • Monitor and graphics card supporting 1024 x 768 resolution
  • 1 free USB port
  • High Speed Internet – Broadband Internet
  • Nexiq USB-Link2 with USB cable (required for Cascadia diagnostics)
  • Administrative Rights (for installation only)
